- SPECIFICATIONS Brand Gigabyte Series VENTUS Series Model GeForce RTX 4060 Ti VENTUS 2X BLACK 16G OC (RTX-4060-Ti-VENTUS-2X-BLACK-16G-OC) Chipset GPU GeForce RTX 4060 Ti Chipset Manufacturer NVIDIA Interface PCIe 4.0 x8 (x16 Physical) Base Clock 2310 MHz Boost Clock Up to 2610 MHz MSI Center Extreme Performance Boost Clock Up to 2625 MHz CUDA Cores 4352 GPU Architecture Nvidia Ada Lovelace Memory Effective Memory Clock 18 Gbps Memory Size 16GB Memory Interface 128-bit Memory Type GDDR6 3D API DirectX 12 Ultimate OpenGL 4.6 Vulkan Vulkan RT API Connectivity Ports 3x DisplayPort 1.4a 1x HDMI 2.1 HDCP Support 2.3 Multi-Monitor Support 4 Maximum Digital Resolution 7680 x 4320 VR Ready Yes General Features MSI VENTUS 2X Cooling System with TORX 4.0 Fans MSI Afterburner Overclocking Utility Metal Back Plate Anti-sag design 3rd Generation Ray Tracing Cores 4th Generation Tensor Cores NVIDIA DLSS 3.0 NVIDIA Reflex NVIDIA Broadcast Resizable BAR NVIDIA GeForce Experience NVIDIA Ansel NVIDIA FreeStyle NVIDIA ShadowPlay NVIDIA Highlights NVIDIA G-SYNC Game Ready Drivers NVIDIA Studio Drivers NVIDIA Omniverse Microsoft DirectX 12 Ultimate NVIDIA GPU Boost NVIDIA NVLink NVIDIA Encoder (NVENC) NVIDIA Decoder (NVDEC) AV1 Encode AV1 Decode Power Requirements Total Board Power 165W Recommended Power Supply 550W Power Connector 1x 8-Pin PEG Connector Physical Aspects Slot Width 2-Slot Form Factor ATX Dimensions 199 x 120 x 42mm (L x W x H) Weight 0.595.kg Warranty Information Warranty 3 Year Warranty
